everyone welcome to controllers tech
0:31
today in this video we will see how to
0:34
gauge and progress bar on nextion
0:40
let's start by creating the project in
0:49
create the project folder here
0:53
give some name and click save
0:56
select your nextion model and select the
1:00
display orientation here
1:05
first of all we need to download a gauge
1:09
let's google for some
1:26
this one seems good for our job
1:29
let's go to this website
1:35
this is 600 by 600 pixels and it's
1:40
let's download it we need to reduce its
1:44
size so it can fit the display
1:52
i have the height here as 240 pixels
1:56
so i will reduce it to the same size
1:59
go to image scale image and reduce the
2:11
let's export it in the same png format
2:21
i am going to create a background now
2:24
the size should be same as the display
2:28
and add that image as a layer here
2:42
i am going to keep a progress bar on the
2:49
let's export this final image
3:12
we need to add the image to our project
3:23
add the image box to the display and
3:26
include the gauge image
3:33
so this will be our background on the
3:37
let's add a progress bar
3:47
i am going to select the vertical type
4:18
if you don't want this white background
4:20
select the background as cropped image
4:27
and select the same image that is in the
4:43
let's change that pointer color and its
4:57
adjust it also try with different values
5:00
to check if the pointer fits the gauge
5:20
okay it's perfect fit now let's add the
5:26
use the cropped image as the background
5:39
we also need to add fonts here
5:42
you can generate them if you don't have
5:50
let's try and put a value to see if it
5:59
great it fits perfectly
6:11
let's test some values on the gauge here
6:26
we don't want the pointer to go here
6:31
so 315 indicates the minimum value on
6:41
but remember this gauge can only rotate
6:47
if i try to go higher than 360
6:50
it will simply not take that value this
6:53
360 and zero are the same positions
6:58
let's try to look for the highest value
7:11
so 225 is the maximum value we can have
7:16
keeping that in mind let's create the
7:29
i am using stm32f446re controller
7:34
give some name to the project and click
7:43
first of all i am selecting the external
7:45
crystal for the clock
7:53
i will be connecting the display to the
7:57
make sure you keep the board rate to
8:06
let's do the clock setup now
8:12
i have eight megahertz oscillator and i
8:14
want the system to run at maximum clock
8:21
click save to generate the project now
8:36
let's first define the end commands
8:38
these must be sent after every command
8:44
create a function to send the value to
8:55
here first define a buffer to hold some
9:02
now copy the data to be sent into the
9:14
and now we will send the buffer to the
9:20
and finally send the end commands
9:34
we need to include s t d i o for the s
9:38
function now if you remember that the
9:41
initial value for the gauge was 315
9:45
so we will add 315 to every value
9:50
and since the gauge can have the maximum
9:54
if the value is higher than 360 we will
9:57
subtract 360 from the value
10:08
now another function to send the data to
10:17
we basically have the same data here
10:27
the same steps for sending the data to
10:30
also basically you can just create a
10:34
single function for all these values
10:42
now in the while loop we will send the
10:44
values to all the elements
10:47
i am using 270 because that's the limit
10:53
first i will send it to the gauge
10:56
the object name is z0 and the value
11:23
next send to the number
11:26
here the object field is n 0 and the
11:49
now before sending the value to the
11:51
progress bar i am going to modify the
11:55
based on the value colors will vary from
11:59
to yellow to orange to red based on the
12:04
if the value is less than 160 we will
12:15
the object name for the bar is j0 and
12:18
the color field is pco
12:21
2016 is the code for the green color
12:24
here you can get different codes for the
12:29
and then based on different values we
12:31
will send the command to change the
12:40
now we will convert the value to the
12:42
percentage so that we can send it to the
12:55
and finally send the value to the value
12:58
filed in the progress bar
13:09
i will add a small delay here
13:23
we need to upload this to the nextion
13:37
i have connected the display to the ftdi
13:40
which is connected to com4
13:46
let's start the upload
13:53
you can see the data is being written to
13:59
and we are done and the images are
14:05
let's upload the code to the board too
14:28
this flickering effect remains with the
14:32
if you want to remove it you need to
14:34
make your own gauge with different set
14:38
i will do that in another video
14:52
we can also simulate the gauge in the
14:55
but for that we need to send the serial
14:57
data to the computer
14:59
and in my nucleo board i have to use
15:01
uart 2 for that purpose
15:13
and i will change these uart4 to you
15:24
in the editor select the debugging and
15:26
select user mcu input
15:32
select the com port and press start
15:41
now i will load the code into the board
15:45
you can see it's pretty smooth here
15:47
compared to the actual display
16:37
let me just reduce the delay to 10
16:49
yes it's a bit faster now
16:57
this is it for this video i hope you
17:02
you can download the code and the gauge
17:05
file from the link in the description
17:08
keep watching and have a nice day ahead
