Hello and welcome to Controllers Tech.
0:11
In this video, we'll be working once
0:16
microcontroller using the Espressive
0:19
IDE. Today's focus is on how to log data
0:23
to the Things Speak Cloud Platform.
0:25
We'll begin by configuring the ESP32 to
0:28
operate in Wi-Fi station mode. This
0:31
means it will connect to an existing
0:33
Wi-Fi network just like your phone or
0:36
laptop connects to a home router. Next,
0:38
we'll configure the ESP32
0:41
to function as an HTTP client. It will
0:45
send HTTP get requests to the ThinkSpe
0:48
cloud to update data on a specific
0:50
channel. These get requests will carry
0:53
the sensor data or any value we want to
0:56
log and the data will be reflected on
0:58
the selected things channel. To make
1:00
things simpler, I'll be using the code
1:03
available from the template projects
1:04
that come bundled within the expressive
1:07
IDE. For this project, I'm using the
1:11
Devkit Vroom 32 development board. If
1:14
you're located in India, you can easily
1:17
purchase this development board from the
1:19
controllers tech online shop. Let's
1:21
begin by launching the expressive IDE
1:24
and creating a new IDF project. Make
1:27
sure to check the option that allows you
1:28
to create a project from the available
1:30
templates. Now, in the search bar, type
1:36
This will display the template project
1:38
that demonstrates the HTTP client. Once
1:41
you see the HTTP client template, click
1:44
okay to generate the project based on
1:46
it. We won't be using this project
1:48
directly. Instead, we'll copy the
1:51
contents of the main file and paste it
1:53
into a text editor for reference. Later
1:56
on, we'll use only the necessary
1:58
functions and parts from this file in
2:01
our actual project. After saving the
2:03
content, you can go ahead and delete
2:05
this template project. Then create a new
2:08
IDF project again. This time in the
2:12
search bar, type Wi-Fi and under the
2:14
getting started folder, choose the Wi-Fi
2:17
station example. This example is useful
2:20
because it helps configure the ESP32 to
2:23
operate in station mode, which we need
2:25
for connecting to an access point. Give
2:28
your project a name that is relevant and
2:30
then click finish to generate the
2:32
project. Now, here we have the main file
2:35
associated with this new project. Let's
2:38
build the project once to make sure
2:40
everything is set up correctly. The
2:42
project compiles successfully without
2:44
any errors. So everything looks good and
2:47
we're ready to move on. The main
2:49
function begins by calling another
2:51
function that is responsible for
2:53
initializing the Wi-Fi in station mode.
2:56
Within this initialization function, we
2:59
need to provide the SSID and password of
3:02
the Wi-Fi network or access point that
3:05
we want the ESP32 to connect to. By
3:09
default, the project retrieves these
3:11
credentials from the SDK configuration
3:14
files. However, we will modify this
3:17
behavior to use values that are defined
3:19
directly in our main source file
3:21
instead. For demonstration, I am using a
3:24
mobile hotspot created on my phone. Here
3:27
I am defining the SSID and password that
3:30
the ESP32 will use to connect to this
3:33
hotspot. We'll also define the maximum
3:36
number of connection attempts. And for
3:39
this example, I'm setting it to five.
3:42
Now, we need to go through the code and
3:44
update all the relevant definitions to
3:46
use the values we've defined manually.
3:49
Once the changes are made, let's build
3:51
the project again to ensure there are no
3:53
compilation errors. As mentioned
3:55
earlier, the main function calls the
4:00
function to initialize the ESP32 in
4:04
station mode. Let's now look at what
4:06
happens inside this function. It starts
4:08
by creating an event group using the
4:11
Xevent group create function. This event
4:13
group will be used later to track the
4:15
connection status whether the ESP32
4:19
successfully connects to the network or
4:21
fails to do so. Next, we initialize the
4:24
TCP IP network interface stack using ESP
4:28
netifinet. After that, we set up the
4:30
default event loop by calling ESP event
4:34
loop create default which is required to
4:36
handle system events. We then create the
4:39
default Wi-Fi station interface using
4:42
the function ESP net of create default
4:44
Wi-Fi STA. This effectively sets the
4:48
ESP32 to operate in station mode,
4:52
preparing it to connect to a Wi-Fi
4:54
network. Following this, we define the
4:57
default Wi-Fi configuration by using the
4:59
macro wifi in nit config default. This
5:03
macro provides default settings that are
5:06
then passed to the ESP WFI init function
5:10
which initializes the Wi-Fi driver with
5:12
those configurations. If you're
5:14
interested, you can review the default
5:16
settings provided in the ESP Wifi.her
5:20
file. Next, we register two event
5:23
handlers to manage Wi-Fi events. The
5:26
first handler is set up to listen to all
5:28
general Wi-Fi related events while the
5:31
second one is specifically configured to
5:34
listen for the IP events. This
5:36
particular event notifies us when the
5:38
ESP32 has successfully connected to the
5:42
network and has obtained an IP address.
5:45
These event handlers play a key role in
5:47
monitoring the state of the Wi-Fi
5:49
connection. They allow us to detect
5:52
important changes such as when the
5:54
connection process starts, whether the
5:56
ESP32 successfully connects or if it
6:00
gets disconnected. Moving forward, we
6:02
define the Wi-Fi SSID and password using
6:06
the Wi-Fi config T structure. These
6:08
credentials were already defined earlier
6:11
at the beginning of the main file. So,
6:13
we'll now make use of them here. By
6:15
default, the Wi-Fi authentication mode
6:21
which is a common and secure method. We
6:24
will leave it unchanged since it matches
6:26
our use case. Now, let me clean up this
6:29
part by removing any unused or
6:32
unnecessary definitions to keep the code
6:34
neat and focused. After setting up the
6:37
configuration, we proceed to configure
6:39
the Wi-Fi mode. We use ESP WiFi set mode
6:43
to set the ESP32 to operate in station
6:46
mode. Then we apply the Wi-Fi
6:49
configuration by calling ESP wifi set
6:52
config and pass the Wi-Fi config T
6:55
structure to it. Finally, we start the
6:58
Wi-Fi driver using the ESP Wi-Fi start
7:02
function which begins the connection
7:04
process based on the defined settings.
7:06
Once the Wi-Fi is started, we wait for
7:09
the connection result by using Xevent
7:11
group weight bits. This function blocks
7:13
the execution until one of the
7:15
predefined event bits is set. Either
7:18
Wi-Fi connected bit or Wi-Fi fail bit.
7:21
These bits are updated by the event
7:23
handler depending on whether the ESP32
7:26
manages to connect successfully or fails
7:29
during the process. Let's go ahead and
7:32
build the project. Now the build process
7:35
completes without any errors which means
7:38
everything is working as expected. So
7:41
let's proceed to flash the code onto the
7:43
ESP32 board. Once the project has been
7:47
successfully flashed, you'll see the
7:49
logs appearing in the console. As shown
7:51
in the log output, the ESP32 has
7:54
successfully connected to the access
7:56
point and it has also obtained an IP
7:59
address. Even though we don't need the
8:01
IP address specifically for this
8:04
project, this confirms that the device
8:06
is now connected to the hotspot that was
8:08
created on the phone. With the Wi-Fi
8:11
connection working properly, the next
8:13
step is to integrate the HTTP client
8:16
code. This will allow us to send data to
8:18
the things cloud. But before diving into
8:21
the code, let's configure things to get
8:24
it ready for receiving data. Open your
8:26
browser and go to things
8:30
Click on the get started button to
8:32
begin. If you don't already have an
8:34
account, you'll need to create one. The
8:36
sign up process is straightforward.
8:39
Since I already have an account, I will
8:41
log into it directly. Now, we'll create
8:44
a new channel that will be used for this
8:46
project. Start by giving a meaningful
8:48
name to the channel, something that
8:50
reflects the purpose of your data
8:52
logging. Things allows us to define up
8:55
to eight fields in a single channel.
8:57
Each of these fields can store different
8:59
types of data. For example, one field
9:03
can hold temperature readings. Another
9:05
can store humidity values and a third
9:08
could be used for pressure data. For
9:10
this demonstration, I'll use two fields.
9:13
One will be used to store temperature
9:15
data and the second will store pressure
9:17
values. You can leave the rest of the
9:19
configuration settings as they are and
9:21
then click on save channel to proceed.
9:24
Once the channel is created, you'll see
9:26
two charts on the page, one for each of
9:29
the fields, temperature and pressure. At
9:32
the top of this page, you can find the
9:34
name of the channel you just created.
9:36
Click on the API keys section. This
9:39
section provides all the necessary
9:41
information for reading from or writing
9:44
data to this channel. Here you'll find a
9:47
write API key which is very important.
9:50
We'll use this key in our code to send
9:53
data to this thing channel. In case the
9:56
API key gets exposed or compromised, you
10:00
also have the option to generate a new
10:02
one easily. Let's begin by copying the
10:04
right API key from the things channel
10:08
settings and defining it as a constant
10:10
in our main file. We'll create a new
10:12
variable named things key to hold this
10:15
key so it can be easily reused in the
10:18
HTTP request. Next, we need to include
10:22
the required header files at the top of
10:24
the main file. Include ESP HTTP client.h
10:29
for handling HTTP communication and
10:33
for managing the network interface. Now
10:36
let's define a new variable called is
10:38
connected and initialize it with a value
10:41
of zero. This variable will act as a
10:44
flag to indicate whether the ESP32 is
10:47
connected to the access point or not.
10:50
Ideally, this flag should be updated
10:52
inside the Wi-Fi event handler. Either
10:55
set when the device successfully
10:57
connects or reset when it disconnects.
11:00
I'll go ahead and update the code as
11:02
well as the article to reflect this
11:04
improvement for better reliability. Now
11:07
let's define a new function whose
11:09
purpose is to send data to the think
11:12
channel. This function will take two
11:14
parameters. The values that we want to
11:16
send to the two fields we created
11:18
earlier in our think channel. Inside
11:20
this function, we'll first configure the
11:23
ESP32 to operate in HTTP client mode.
11:27
Then we'll use it to send the formatted
11:29
data to the things server. To begin,
11:32
let's define a character array that will
11:34
be used to store the complete URL
11:36
string. We'll then use the sprint
11:38
function to construct the full things
11:41
URL and copy it into our array. This URL
11:45
is used to write data to the things
11:47
channel through an HTTP get request.
11:51
You'll notice that by default, the URL
11:53
structure only supports a single field.
11:56
So, we'll be modifying it in the code to
11:58
accommodate multiple fields. For now,
12:01
let's place the basic URL into our code
12:04
and change the protocol from HTTPS to
12:07
HTTP as it's simpler and doesn't require
12:10
certificate handling. Next, delete the
12:13
hard-coded API key from the URL.
12:16
Instead, we'll use a string format
12:19
specifier percent s to insert the key
12:22
dynamically at runtime. This key will be
12:25
taken from the things key variable we
12:28
defined earlier. Now remove the fixed
12:30
field value and replace it with an
12:32
integer format specifier percent d
12:35
allowing us to pass the actual data as
12:38
function parameters. Since we are
12:40
sending data to two fields, we'll add
12:43
one more field to the URL and include
12:46
another integer format specifier for the
12:48
second value. Finally, we'll pass both
12:51
the API key and the two data values to
12:54
the sprint function so they get inserted
12:56
in the correct places in the URL. With
12:59
this, our full URL is now properly
13:02
formatted and ready to be sent using the
13:04
HTTP client. Now, we will begin using
13:07
the relevant functions from the HTTP
13:10
client code that we copied earlier.
13:12
Navigate to the function named HTTP rest
13:15
with URL in that template. From this
13:18
function, let's copy the HTTP client
13:21
config structure and the code that
13:24
initializes this configuration. Let's
13:26
first take a look at what this
13:28
configuration structure includes. One of
13:30
the key members of this structure is a
13:32
pointer to the URL. When this field is
13:35
provided, it overrides several other
13:38
fields such as the host, username,
13:40
password, and path. So instead of
13:44
defining each of those fields
13:45
separately, we'll remove the predefined
13:48
ones and just define the URL field
13:50
directly. Paste the URL that we
13:53
constructed earlier into this
13:55
configuration structure. Next, set the
13:58
method field to configure the HTTP get
14:01
method since we're sending data using a
14:04
Git request. That's all we need. These
14:07
two fields, the URL and the method, are
14:10
sufficient for our project. Now we will
14:13
use the HTTP client functions relevant
14:16
to sending a GET request. Let's remove
14:18
the log function used for printing the
14:20
HTTP response since we're not using the
14:23
response data in this project. Finally,
14:26
after the HTTP request has been
14:28
processed, make sure to call ESP HTTP
14:32
client cleanup to properly delete and
14:34
free the HTTP client instance. Just like
14:38
the get method, the template code also
14:40
includes functions for other HTTP
14:42
methods like post, put, patch, delete,
14:46
and so on, which you can use depending
14:48
on your project requirements. That
14:50
covers the setup part. Now, let's define
14:53
a while loop so that we can continuously
14:55
send data to things at regular
14:58
intervals. Inside this loop, we'll first
15:00
check if the is connected flag is set.
15:03
This ensures that the ESP32
15:06
only sends data when it's connected to
15:08
the Wi-Fi access point. Let's define a
15:11
couple of integer variables to store
15:13
some dummy values for now. In a real
15:15
world project, you would replace these
15:18
with values read from actual sensors.
15:20
Once we've assigned or read the values,
15:23
we'll send them to the things speak
15:25
channel using the function we defined
15:27
earlier. After each data transmission,
15:30
we'll wait for at least 15 seconds
15:32
before sending the next set of data.
15:34
This is important because ThSpeak
15:37
enforces a minimum update interval of 15
15:40
seconds for free accounts. Let's also
15:43
log the values that are being sent so we
15:45
can see them on the serial console. All
15:47
right, let's now build the project to
15:50
make sure everything compiles. There are
15:52
no errors, so we can go ahead and flash
15:55
the project onto the ESP32 board. On the
15:58
serial console, you can see the data
16:00
being sent. The first values are 75 and
16:04
55. Now, if you check on the ThinkPe
16:07
cloud dashboard, you'll see that these
16:09
same values have been updated in the
16:11
corresponding fields. Next, we have
16:14
another set of values 49 and zero, which
16:17
are also reflected on the things graphs
16:19
in real time. Following that we get 35
16:23
and 81. Again the same values are
16:26
correctly displayed on the channel. This
16:29
confirms that our ESP32
16:31
is successfully logging sensor data to
16:34
the things speak platform. You also have
16:36
the option to make your things speak
16:38
channel public which means anyone with
16:41
the correct link can view the data
16:43
remotely from anywhere in the world. In
16:45
addition to line charts, you can add
16:47
various types of widgets to enhance the
16:49
visualization like gauges, numeric
16:52
displays, lamps, and more. Here I've
16:56
added a gauge widget that is configured
16:58
to display data from field one. The
17:00
gauges range is set from 0 to 100 to
17:03
match the expected values. As you can
17:06
see, the gauge updates in real time and
17:09
accurately reflects the value received
17:12
from field one. Everything is working
17:14
exactly as intended. So, I hope this
17:17
video helped you understand how to
17:19
configure the ESP32's Wi-Fi in station
17:22
mode, how to connect it to an access
17:24
point, and how to send data to the
17:26
Things Speed Cloud using HTTPG requests.
17:30
That's all for this video. In the next
17:32
one, we'll explore how to use the ESP32
17:36
in station mode to publish a topic to an
17:38
MQTT broker. You can download this
17:41
complete project from the link provided
17:43
in the description below. Feel free to
17:45
leave a comment if you have any
17:47
questions or doubts. Thanks for watching
17:49
and have a great day ahead.
