Fingerprint Authentication with STM32 & R307 | Enroll, Store & Match FP Data
Aug 23, 2025
In this video, we will interface the R307 Fingerprint Sensor with the STM32 microcontroller. You’ll learn how to enroll fingerprints, store them in the module’s memory, and perform fingerprint matching to control outputs. This is a complete hands-on demo that shows the working of biometric authentication on STM32. 📂 Download Project Files: 👉 https://controllerstech.com/interface-r307-fingerprint-module-with-stm32/ 📺 Related Videos: 👉STM32 UART Tutorial : https://youtu.be/KdXSRyPCYuM Don’t forget to Like 👍, Share 🔄, and Subscribe 🔔 for more STM32 tutorials and embedded projects. #STM32 #FingerprintSensor #R307 #EmbeddedSystems #STM32Projects #BiometricSecurity #Microcontrollers #ElectronicsProjects #Controllerstech ________________________________________________________________________________________ Facebook Page : https://www.facebook.com/controllerstech Telegram Group : https://t.me/controllerstechdiscuss Instagram : https://www.instagram.com/controllerstech/
View Video Transcript
0:09
Hello and welcome to Controllers Tech.
0:11
In today's video, we're going to learn
0:14
how to interface the R307
0:16
fingerprint sensor module with an STM32
0:20
microcontroller. The R307
0:23
is an optical fingerprint scanner that
0:25
comes with a built-in DSP chip. What
0:28
this means is that the module not only
0:31
captures the fingerprint image but also
0:33
processes it internally. It takes care
0:36
of converting the image into a
0:38
fingerprint template that can be used
0:40
directly. So the microcontroller does
0:43
not need to handle heavy image
0:45
processing or recognition tasks. Another
0:48
key advantage of this sensor is its
0:50
storage capacity. The R307 can store up
0:54
to 1,000 fingerprint templates in its
0:56
internal memory. With just a few simple
0:59
commands, you can easily add new
1:01
fingerprints, search for existing ones,
1:04
or even delete entries when required.
1:07
The communication is also very
1:09
straightforward. The sensor uses UR or
1:13
the serial interface, which makes it
1:15
widely compatible with different
1:17
platforms. Whether you're working with
1:19
Arduino, STM32,
1:21
ESP32,
1:23
or even Raspberry Pi, the module could
1:26
be connected without difficulty. For
1:28
this demonstration, I'm going to use the
1:31
STM32F446
1:34
development board from WAX Studio. If
1:36
you're located in India, you can
1:38
conveniently purchase this board from
1:40
shop.controllerssteech.com.
1:42
Now, let's move to Cube IDE and begin by
1:46
creating a new project. As mentioned
1:48
earlier, I will be using the STM32F446RE
1:54
base development board. Give the project
1:56
a suitable name and then click on finish
1:58
to create it. The first step after
2:01
project creation is the clock
2:02
configuration. I will be using the
2:05
internal clock source and setting it to
2:07
run the system at the maximum frequency
2:10
of 180 MHz. Next, go to the system
2:14
settings, open the debug option, and
2:16
enable serial wire debug to make
2:19
debugging easier. Since the fingerprint
2:21
module communicates through UE, I will
2:24
configure UE4 for this purpose as it
2:28
provides a convenient connection option.
2:30
Enable the UE in asynchronous mode. The
2:33
R37 sensor uses a default baud rate of
2:37
57,600
2:39
bps. The word length should be set to 8
2:42
bits with no par and one stop bit. In
2:45
addition to this, I will enable one more
2:48
UE channel to display logs during
2:51
testing. On this board, the UR1 pins are
2:54
easier to access, so I will use them for
2:57
logging. You can set any baud rate for
2:59
the log UR, but I'm going to configure
3:02
it to 115,200
3:05
bps. I'm also going to connect two LEDs
3:08
to the board. These LEDs will serve as
3:11
indicators. One will turn on if the
3:13
fingerprint matches and the other will
3:15
turn on if it does not match. So in
3:18
CubMx, set two pins as output mode.
3:21
These will be used to connect the LEDs.
3:25
That completes all the configuration we
3:27
need in CubMX. Now click on save to
3:30
generate the project code. Before moving
3:33
forward with the coding part, let's take
3:34
a quick look at the hardware schematic.
3:37
Here we have the R307S
3:40
fingerprint sensor module. Functionally,
3:42
it is the same as the R307.
3:46
The only difference is the size of the
3:48
PCB. The connector on this module has
3:51
pins labeled from 1 to six. Let's go
3:54
through them one by one. Pin one is the
3:56
VCC pin. This should be connected to the
3:59
5V pin on the STM32 board. The good
4:03
thing is the module automatically
4:06
converts this supply voltage to safe TTL
4:09
levels for UET communication. So it is
4:11
completely safe to connect it directly
4:13
to 5 Vs. Pin 2 is the ground pin and as
4:18
expected it should be connected to the
4:20
ground of the STM32.
4:23
Pin 3 is the ueTX pin of module. This
4:27
pin must be connected to the RX pin of
4:29
the STM32.
4:31
Since I'm using UERT4, this pin will go
4:34
to PA1. Pin 4 is the URX
4:38
pin, which should be connected to the TX
4:40
pin of the STM32.
4:43
Again, since Urt4 is being used, this
4:46
pin connects to PA0, which is the
4:49
Urt4TX.
4:51
The remaining pins of the connector are
4:53
not required for our project. So, we
4:55
will leave them unconnected. Now, let's
4:57
look at the LEDs. I have connected two
5:00
LEDs to pins PC0 and PC1. When a finger
5:05
placed on the sensor matches with the
5:07
data stored in the database, the green
5:09
LED will light up. If the fingerprint
5:12
does not match, the red LED will turn on
5:15
instead. For debugging and monitoring, I
5:18
am using Urt1 to output logs. Here the
5:22
STM 32 pin PA10 U31TX is connected to
5:27
the RX pin of a USB TURT module and this
5:30
module is then connected to the computer
5:33
using a USB cable. That's all for the
5:35
wiring diagram. Now let's move ahead and
5:38
continue with the project. Here I
5:40
already have the library files prepared
5:42
for the R307
5:44
sensor and we will copy them into our
5:47
project. Place the C file inside the
5:50
source directory and a header file
5:52
inside the include directory of the
5:54
project. Let's begin by opening the
5:56
header file. In this file, you first
5:58
need to define the UR instance that
6:00
you're using to communicate with the
6:02
R307 sensor. This is important as the
6:06
library functions depend on the correct
6:08
UR configuration. If you run into any
6:11
issues during development, you can
6:13
enable debug logs by setting the debug
6:16
variable to one. With this option
6:18
enabled, the library will print detailed
6:20
logs for every step of execution, which
6:23
is very helpful for troubleshooting. The
6:26
main logs should always remain enabled
6:29
as they provide information about the
6:30
user interaction with the sensor. For
6:33
logging, I have used the standard printf
6:36
function. This makes it easier for us to
6:39
format and display the log data clearly
6:42
on the terminal. That's all the
6:44
configuration required in the header
6:46
file. Now let's move to the source file
6:48
and see the available functions along
6:50
with their usage. The R37
6:54
enroll function is used to enroll a
6:56
fingerprint. It requires a parameter
6:59
called page ID which is simply the
7:01
location number where the fingerprint
7:03
will be stored inside the sensor's
7:05
memory. The R307 sensor is capable of
7:08
storing up to 1,000 fingerprints with
7:12
IDs ranging from 1 to 1,000. Next is the
7:15
R307
7:17
verify function. This function captures
7:20
a fingerprint image and searches through
7:22
the database to find a matching
7:24
template. It has two parameters. out
7:27
page ID which returns the ID of the
7:30
match fingerprint and score which
7:32
indicates how closely the captured
7:34
fingerprint matches the stored template.
7:36
Another useful function is verify
7:39
password. This is used to verify the
7:41
module's handshaking password. It takes
7:44
the password as a parameter and returns
7:47
how okay if the verification is
7:49
successful. If the password verification
7:52
fails, you can use the set password
7:54
function to set a new password for the
7:56
sensor. This function accepts the new
7:59
password as its parameter. There are
8:01
also functions to manage stored
8:04
fingerprints. For example, clear all
8:06
fingerprints will erase all the
8:08
fingerprints stored in the sensor's
8:10
memory. And the delete fingerprints
8:12
function can delete a specific number of
8:15
fingerprints starting from any given
8:17
page ID. To understand how these
8:19
functions work internally, let's take a
8:22
look at the R307 data sheet and scroll
8:25
down to the section describing the
8:27
command details. Here we can see the
8:29
general format of a command that needs
8:31
to be sent to the R307.
8:34
It begins with two bytes of header which
8:36
is always 0x EF01.
8:40
This is followed by four bytes of the
8:42
module address. By default, the module
8:45
address is set to 0x FF ff,
8:51
but it can be modified using specific
8:53
commands. Next, there is a one byte
8:56
package identifier. This bite helps the
8:59
sensor determine whether the packet
9:01
being sent is a command packet or a data
9:03
packet. After that, we have two bytes of
9:06
length which specify the total length of
9:09
the instruction code, parameter bytes,
9:11
and check sum. The instruction code
9:14
comes next. For example, 0x13
9:18
is the instruction code for the verify
9:20
password command. The instruction code
9:23
is followed by parameter bytes. In the
9:25
case of the verify password command, the
9:28
parameters would be four bytes
9:30
representing the password we want to
9:32
verify with the module. Finally, we add
9:35
two bytes of check sum which completes
9:38
the command packet. When the R307
9:41
receives a command, it responds with a
9:43
packet in a similar format. The first
9:46
six bytes which contain the header and
9:48
address remain unchanged. The package
9:52
identifier in the response is 0x07
9:56
which represents an acknowledgement
9:58
packet. Then we again have two bytes of
10:01
length followed by the confirmation code
10:03
and finally two bytes of check sum. The
10:06
confirmation code will vary depending on
10:08
the instruction. For example, in the
10:11
verify password command, the
10:13
confirmation code can be zero if the
10:15
password is correct, one if there was an
10:18
error in receiving the command or 13 if
10:21
the password is incorrect. Now let's see
10:24
how all of this is actually implemented
10:26
in the code. To keep things clear, I
10:29
will take the example of the verify
10:31
password command. The first step is to
10:33
prepare the parameters. Since the
10:35
password is 32 bits, we need to break it
10:39
down into four separate bytes. Once the
10:41
parameters are ready, we call the
10:43
function build command to construct the
10:46
final command packet. The function build
10:48
command takes a few parameters. The
10:51
first parameter is the structure where
10:53
the complete command will be stored. The
10:56
second parameter is the instruction code
10:58
itself. Next, we provide the instruction
11:01
parameters. And finally we pass the
11:04
number of parameter bytes inside the
11:06
build command function. The process
11:09
begins by inserting the header and the
11:11
device address at the start of the
11:12
buffer. After that the package
11:15
identifier is added. In this case the
11:18
identifier will be set to command. Next
11:21
the function calculates the total length
11:24
of the command package. This length
11:26
includes one bite for the instruction
11:28
code, the number of instruction
11:30
parameters and two bytes for the check
11:32
sum. Once the length is calculated, the
11:35
function copies the length, the
11:37
instruction code and the parameters into
11:40
the command buffer. Finally, it
11:42
calculates the check sum. The check sum
11:44
is obtained by adding all the data
11:47
starting from the sixth position in the
11:49
buffer. Once calculated, the checksum
11:52
bytes are also copied into the buffer.
11:55
At this point, the command buffer is
11:57
complete and it is ready to be sent to
11:59
the sensor through u. Now let's see how
12:02
these functions are used inside the main
12:05
C file. First include the R307
12:09
header file and then define a write
12:11
function for redirecting the printf
12:13
output. Here we will redirect all print
12:16
f outputs to ur1 which we already
12:19
configured earlier for logging. Inside
12:22
the main function, we start by calling
12:24
the function to verify the sensor
12:26
password. The default password is zero.
12:30
And if this matches the sensor's
12:32
password, the function will return how
12:35
okay. If the verification fails, we will
12:38
print the error logs on the terminal and
12:40
then call the error handler function. In
12:42
case the password does not match, you
12:45
can also call the function to set a new
12:47
password and then verify it again with
12:49
the sensor. Once the password step is
12:52
successful, the next task is to clear
12:54
all the fingerprints stored in the
12:56
sensor's memory. After clearing, we will
12:59
proceed to enroll a new fingerprint at
13:02
page ID 1. Here the program will print a
13:05
message asking the user to place their
13:07
finger on a sensor. When a user places
13:10
the finger, the enroll function will be
13:12
called. This function handles the
13:14
complete process. It captures the image,
13:18
converts it into character data and
13:20
finally stores at the specified memory
13:22
location inside the sensor. If the
13:24
process is successful, the function will
13:27
return how underscore okay. Next, we
13:30
move on to verifying a fingerprint. For
13:32
this, we first define two 16 bit
13:35
variables, one for the match page ID and
13:39
one for the score. The program will then
13:41
prompt the user to place a finger on the
13:43
sensor for verification. After that we
13:46
call the verify function. This function
13:49
captures the fingerprint image, searches
13:51
the database of stored fingerprints and
13:54
tries to find match. If a match is
13:56
found, the match page ID will be stored
13:59
in the variable we defined earlier and
14:01
the score will be stored in the score
14:03
variable. The score indicates how
14:05
closely the fingerprint matches with the
14:07
store template. The higher the score,
14:10
the better the match. In general, a
14:12
decent match will have a score of around
14:15
150 or more. That's all we need to get
14:18
the sensor tested for the first time. So
14:20
now let's go ahead and build the
14:22
project. The build is successful and
14:25
there are no errors. So the final step
14:27
is to flash the code to the STM32 board.
14:31
Now let's open the serial port that is
14:33
connected to UERT1 so we can view the
14:36
logs from the board. I will reset the
14:38
board once to start the process from the
14:40
beginning. As you can see in the logs,
14:43
the password verification is successful
14:46
and the sensor has been initialized
14:48
correctly. Now the program is asking us
14:50
to place a finger on the sensor. The
14:53
fingerprint will be stored at page ID1.
14:56
For this demo, I'm going to use my right
14:58
thumb. You can see in the logs that the
15:00
first image has been successfully
15:02
captured and converted. At this point,
15:04
we need to remove the finger and place
15:07
it again. After capturing the second
15:09
image, the sensor automatically merges
15:12
both images and generates a combined
15:15
template that completes the enrollment
15:17
process. And now the verify function
15:20
begins execution. Let's place the same
15:22
finger again. The logs confirm that a
15:25
match has been found at ID1 with a match
15:28
score of 352,
15:30
which indicates a very strong match. Now
15:33
let's reset the board once more to test
15:35
another case. This time I will register
15:38
the thumbrint again, but for
15:40
verification I will place my index
15:42
finger instead. As expected, the
15:44
fingerprint does not match the database.
15:47
So no match is found. To make the sensor
15:50
continuously check for fingerprints, I
15:52
have placed the verify function inside
15:55
the while loop. I have also added a
15:58
delay of 1 second before each new
16:00
verification. So the function will wait
16:03
before checking the next fingerprint.
16:05
Let's build the project again and flash
16:07
it to the board. We'll first complete
16:09
the enrollment process once more. Now
16:13
let me try verifying with my index
16:15
finger again. Since this fingerprint was
16:17
not stored earlier, there is no match
16:19
found. Because the verify function is
16:22
running inside the while loop, it
16:24
immediately asks for another fingerprint
16:27
again. Now let's try the thumb once
16:28
more. And as expected, this time the
16:31
match is found successfully. The verify
16:34
function continues to run in the
16:36
background, checking the sensor for new
16:38
fingerprints each time. So far,
16:41
everything is working exactly as
16:43
intended. However, there is one
16:45
important thing to note. Every time the
16:47
system reboots, the functions for
16:50
password verification, clearing
16:52
fingerprints, and enrollment will run
16:54
again. But we do not want to reenroll
16:56
fingerprints after every reboot.
16:59
Instead, these functions should only run
17:01
when we specifically need them. To
17:03
achieve this, we can use udt commands to
17:06
decide which function should run at
17:08
runtime. Although I am not implementing
17:10
full udert control here. I will simply
17:13
block these functions after the first
17:15
run. One way to do this is by storing a
17:18
value in the flash memory and checking
17:21
it during runtime. But since writing to
17:23
flash requires more effort, I will use a
17:26
simpler approach. we could take
17:28
advantage of the RDC backup register
17:30
which I also explained in detail during
17:33
the RDC tutorial. So let's go back to
17:35
cube MX and enable the RDC peripheral.
17:39
Do not enable anything else since we
17:42
only need its backup register
17:43
functionality. Now I have replaced the
17:45
earlier code with the updated logic.
17:48
First we define a variable to store how
17:51
many fingerprints we want to enroll. At
17:53
the beginning, we will verify the sensor
17:56
password as usual. Then we will check if
17:59
the RDC backup register already contains
18:02
this value. On the first run, this value
18:05
will not be present. So the code inside
18:07
the condition will execute. Here we will
18:10
first clear all the stored fingerprints.
18:13
Next, we will run the enrollment
18:15
function for as many fingerprints as
18:17
needed. Since storage in the sensor
18:20
begins from page ID 1, the loop variable
18:22
should also start at one. I have also
18:25
added retry functionality. So if
18:28
enrollment fails for a particular
18:30
finger, the program will attempt it
18:32
again. Once the required number of
18:34
fingerprints are successfully enrolled,
18:36
we will write the value into the RDC
18:39
backup register. This ensures that
18:41
enrollment will not run again the next
18:44
time the system reboots. After the
18:46
initial setup is complete, the program
18:49
moves to the main verification loop.
18:51
Here we continuously call the verify
18:54
function and based on its result, we
18:57
control the LEDs. First, we define the
19:00
LED ports and their pins. If the verify
19:04
function does not find a match, the red
19:07
LED will turn on to indicate failure.
19:10
Otherwise, if the fingerprint matches,
19:12
the green LED will turn on clearly
19:15
indicating that the match has been
19:17
found. After this indication, we will
19:19
wait for about 2 seconds and then turn
19:22
off both LEDs to reset the status. Let's
19:25
build the project now. It looks like
19:27
there is a small error in the pin
19:29
definition. Let me correct that and
19:32
rebuild the project again. Now,
19:34
everything compiles successfully. So
19:36
let's flash the code to the STM32 board.
19:39
First, I will enroll my right thumb. The
19:42
thumb has now been enrolled successfully
19:44
and stored at page ID 1. Next, I will
19:47
enroll my right index finger at page ID
19:50
2. With both fingers stored, let's go
19:53
ahead and verify them. As you can see,
19:56
when the correct finger is placed on the
19:58
sensor, the green LED lights up,
20:01
confirming the match. Now, let's try
20:03
with my left thumb. This time the
20:05
fingerprint is not found in the database
20:08
and therefore the red LED turns on. I
20:11
will try with my left index finger as
20:13
well. Again there is no match and the
20:16
red LED turns on to indicate failure.
20:19
But when I place the correct registered
20:21
finger again, the green LED turns on
20:24
once more. So everything is functioning
20:27
exactly as expected and our fingerprint
20:30
sensor is working perfectly. In addition
20:32
to what we tested here, you can also
20:34
make use of many more instructions
20:36
available in the data sheet. For
20:38
example, if you want to enroll multiple
20:41
fingerprints from different people at
20:43
different times and store them all, you
20:45
can use instruction 7, which checks
20:47
whether a template already exists at a
20:49
specific page ID. If the template is
20:52
present, the function will return okay,
20:55
and you can skip storing at that
20:56
location to avoid overwriting existing
20:59
data. Similarly, instruction 15 allows
21:02
you to change the device address if
21:04
needed. Now, let me quickly show you
21:07
some of the additional functions
21:08
available in the library. One such
21:11
function waits for a finger to be placed
21:14
on the sensor. It uses a timeout
21:16
feature. So, if the user does not place
21:19
their finger within the given time, the
21:21
function returns a timeout error. Inside
21:24
the enrollment function, I have set this
21:26
time out to 20 seconds, giving the user
21:29
enough time to place their finger on the
21:31
sensor. There's also another function
21:34
which waits for the finger to be removed
21:36
from the sensor before continuing. As I
21:39
mentioned at the beginning, you can
21:40
enable the debug logs to print detailed
21:43
debug level messages on the console.
21:46
These logs are generated from inside the
21:48
static functions and can be very helpful
21:50
in identifying and debugging any issues
21:53
with the sensor. So with this we have
21:56
successfully interfaced the R307
21:59
fingerprint sensor with an STM32
22:02
microcontroller using the URT interface.
22:05
The sensor can store up to 1,000
22:07
fingerprints which means it is suitable
22:10
for projects where you need to register
22:12
a large number of users. You can also
22:14
extend this project by controlling the
22:16
sensors operations using Urarti commands
22:19
or even building a GUI on a display to
22:22
make it more userfriendly. Let me know
22:24
in the comments if you would like me to
22:26
create a video demonstrating how to use
22:28
the sensor with a GUI interface. That is
22:31
all for this video. You can download the
22:34
complete project from the link given in
22:36
the description. If you have any
22:38
questions or doubts, feel free to leave
22:40
them in the comment section. Thank you
22:42
for watching and have a nice day ahead.
#Computers & Electronics
#Electronic Components
